But Weld fittings Con / Ecc Reducer ASTM A860 WPHY 70 / WPHY 65 / WPHY 60 1” To 48” SCH10 To SCH160
| Place of Origin | CHINA |
|---|---|
| Brand Name | TOBO |
| Certification | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number | ASTM A860 WPHY 70 / WPHY 65 / WPHY 60 |
| Minimum Order Quantity | 3PCS |
| Price | Negotiation |
| Packaging Details | PLY-WOODEN CASE OR PALLET |
| Delivery Time | 15DAYS |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 9980000PCS Per Month |
Product Details
| Products Name | But Weld Fittings Con / Ecc Reducer | Material | ASTM A860 WPHY 70 / WPHY 65 / WPHY 60 |
|---|---|---|---|
| Thickness | Sch5-Sch160, STD, XS, XXS | Standard | ANSI/ASTM B16.9 |
| Surface Finish | Sand Blast, Black Painting, Galvanizing Finish | Manufacturing Process | Push, Press, Forge, Cast, Etc. |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc | ||
| Highlight | butt weld tube fittings,butt welded pipe fittings |
||
Product Description
But Weld fittings Con / Ecc Reducer ASTM A860 WPHY 70 / WPHY 65 / WPHY 60 1” To 48” SCH10 To SCH160
A.Eccentric reducer
Process: stainless steel, nickel-copper used in cold molding; such as carbon steel used in thermal processing Die Molding
Dimensions: seamless 1 / 2 "-20" (DN15 - DN500), a slit 1 / 2 "-48" (DN15 - DN1200)
Standards:GB/T12459,GB/T13401,SH3408,SH3409,HG/T21635,
HG/T21631,ASME B16.9,MSS SP-43,DIN 2616,JIS B2313
Thickness:SCH5S-SCH160
Material: Stainless steel, nickel copper, carbon steel and low alloy steel, alloy steel
B.Concentric reducer
Process: stainless steel, nickel-copper used in cold molding; such as carbon steel used in thermal processing Die Molding
Dimensions: seamless 1 / 2 "-20" (DN15 - DN500), a slit 1 / 2 "-48" (DN15 - DN1200)
Standards: GB/T12459,GB/T13401,SH3408,SH3409,HG/T21635,
HG/T21631,ASME B16.9,MSS SP-43,DIN 2616,JIS B2313
Thickness:SCH5S-SCH160
Material: Stainless steel, carbon steel and alloy steel
ASME B16.9
|
Tube Dimension |
Outer diameter OD1 |
Outer diameter OD2 |
Wall thickness (T) |
Length H |
Reducer |
||||||||
|
Sch.5S |
Sch.10S |
Sch.40S |
Sch.80S |
Center to the end of C |
Center to the end of M |
||||||||
|
T |
T2 |
T1 |
T2 |
T1 |
T2 |
T1 |
T2 |
||||||
|
3/4x1/2 |
1.050 |
0.840 |
0.065 |
0.065 |
0.083 |
0.083 |
0.133 |
0.109 |
0.154 |
0.147 |
1.50 |
1.13 |
1.13 |
|
1x1/2 |
1.315 |
0.840 |
0.065 |
0.065 |
0.109 |
0.083 |
0.133 |
0.109 |
0.179 |
0.147 |
2.00 |
1.50 |
1.50 |
|
1x3/4 |
1.315 |
1.050 |
0.065 |
0.065 |
0.109 |
0.083 |
0.113 |
0.113 |
0.179 |
0.154 |
2.00 |
1.50 |
1.50 |
|
1-1/4x1 |
1.660 |
1.315 |
0.065 |
0.065 |
0.109 |
0.109 |
0.140 |
0.133 |
0.191 |
0.179 |
2.00 |
1.88 |
1.88 |
|
1-1/2x1/2 |
1.900 |
0.84 |
0.065 |
0.065 |
0.109 |
0.083 |
0.145 |
0.109 |
0.200 |
0.147 |
2.50 |
2.25 |
2.25 |
|
1-1/2x3/4 |
1.900 |
1.050 |
0.065 |
0.065 |
0.109 |
0.083 |
0.145 |
0.113 |
0.200 |
0.154 |
2.50 |
2.25 |
2.25 |
|
1-1/2x1 |
1.905 |
1.315 |
0.065 |
0.065 |
0.109 |
0.109 |
0.145 |
0.113 |
0.200 |
0.179 |
2.50 |
2.25 |
2.25 |
|
1-1/2x1-1/4 |
1.900 |
1.660 |
0.065 |
0.065 |
0.109 |
0.109 |
0.145 |
0.140 |
0.200 |
0.191 |
2.50 |
2.25 |
2.25 |
|
2x3/4 |
2.375 |
1.050 |
0.065 |
0.065 |
0.109 |
0.083 |
0.154 |
0.113 |
0.218 |
0.154 |
3.00 |
2.50 |
1.75 |
|
2x1 |
2.375 |
1.315 |
0.065 |
0.065 |
0.109 |
0.109 |
0.154 |
0.133 |
0.218 |
0.179 |
3.00 |
2.50 |
2.00 |
|
2x1-1/4 |
2.375 |
1.660 |
0.065 |
0.065 |
0.109 |
0.109 |
0.154 |
0.140 |
0.218 |
0.191 |
3.00 |
2.50 |
2.25 |
|
2x1-1/2 |
2.375 |
1.900 |
0.065 |
0.065 |
0.109 |
0.109 |
0.154 |
0.145 |
0.218 |
0.200 |
3.00 |
2.50 |
2.38 |
|
2-1/2x1 |
2.875 |
1.315 |
0.083 |
0.065 |
0.120 |
0.109 |
0.203 |
0.133 |
0.276 |
0.179 |
3.50 |
- |
- |
|
2-1/2x1-1/4 |
2.875 |
1.660 |
0.083 |
0.065 |
0.120 |
0.109 |
0.203 |
0.140 |
0.276 |
0.191 |
3.50 |
3.00 |
2.50 |
|
2-1/2x1-1/2 |
2.875 |
1.900 |
0.083 |
0.065 |
0.120 |
0.109 |
0.203 |
0.145 |
0.276 |
0.200 |
3.50 |
3.00 |
2.63 |
|
2-1/2x2 |
2.875 |
2.375 |
0.083 |
0.065 |
0.120 |
0.109 |
0.203 |
0.154 |
0.276 |
0.218 |
3.50 |
3.00 |
2.75 |
|
3x1 |
3.500 |
1.315 |
0.083 |
0.065 |
0.120 |
0.109 |
0.216 |
0.133 |
0.300 |
0.179 |
3.50 |
- |
- |
|
3x1-1/4 |
3.500 |
1.660 |
0.083 |
0.065 |
0.120 |
0.109 |
0.216 |
0.140 |
0.300 |
0.191 |
3.50 |
- |
- |
|
3x1-1/2 |
3.500 |
1.900 |
0.083 |
0.065 |
0.120 |
0.109 |
0.216 |
0.145 |
0.300 |
0.200 |
3.50 |
3.13 |
2.88 |
|
3x2 |
3.500 |
2.375 |
0.083 |
0.065 |
0.120 |
0.109 |
0.216 |
0.154 |
0.300 |
0.218 |
3.50 |
3.38 |
3.00 |
|
3x2-1/2 |
3.500 |
2.875 |
0.083 |
0.083 |
0.120 |
0.120 |
0.216 |
0.203 |
0.300 |
0.276 |
3.50 |
3.38 |
3.25 |
|
4x1-1/2 |
4.500 |
1.900 |
0.083 |
0.065 |
0.120 |
0.109 |
0.237 |
0.145 |
0.337 |
0.200 |
4.00 |
4.13 |
3.38 |
|
4x2 |
4.500 |
2.375 |
0.083 |
0.065 |
0.120 |
0.109 |
0.237 |
0.154 |
0.337 |
0.218 |
4.00 |
4.13 |
3.50 |
|
4x2-1/2 |
4.500 |
2.875 |
0.083 |
0.083 |
0.120 |
0.120 |
0.237 |
0.203 |
0.337 |
0.276 |
4.00 |
4.13 |
3.75 |
|
4x3 |
4.500 |
3.500 |
0.083 |
0.083 |
0.120 |
0.120 |
0.237 |
0.216 |
0.337 |
0.300 |
4.00 |
4.13 |
3.88 |
|
5x3 |
5.563 |
3.500 |
0.109 |
0.083 |
0.134 |
0.120 |
0.258 |
0.216 |
0.375 |
0.300 |
5.00 |
4.88 |
4.38 |
|
5x4 |
5.563 |
4.500 |
0.109 |
0.083 |
0.134 |
0.120 |
0.258 |
0.237 |
0.375 |
0.337 |
5.00 |
4.88 |
4.63 |
|
6x2-1/2 |
6.625 |
2.875 |
0.109 |
0.083 |
0.134 |
0.120 |
0.280 |
0.203 |
0.432 |
0.276 |
5.50 |
5.63 |
4.75 |
|
6x3 |
6.625 |
3.500 |
0.109 |
0.083 |
0.134 |
0.120 |
0.280 |
0.216 |
0.432 |
0.300 |
5.50 |
5.63 |
4.88 |
|
6x4 |
6.625 |
4.500 |
0.109 |
0.083 |
0.134 |
0.130 |
0.280 |
0.237 |
0.432 |
0.337 |
5.50 |
5.63 |
5.13 |
|
6x5 |
6.625 |
5.563 |
0.109 |
0.109 |
0.134 |
0.134 |
0.280 |
0.258 |
0.432 |
0.375 |
5.50 |
5.63 |
5.38 |
|
8x4 |
8.625 |
4.500 |
0.109 |
0.083 |
0.148 |
0.120 |
0.322 |
0.237 |
0.500 |
0.337 |
6.00 |
7.00 |
6.13 |
|
8x5 |
8.625 |
5.563 |
0.109 |
0.109 |
0.148 |
0.134 |
0.322 |
0.258 |
0.500 |
0.375 |
6.00 |
7.00 |
6.38 |
|
8x6 |
8.625 |
6.625 |
0.109 |
0.109 |
0.148 |
0.134 |
0.322 |
0.280 |
0.500 |
0.432 |
6.00 |
7.00 |
6.63 |
|
10x5 |
10.750 |
5.563 |
0.134 |
0.109 |
0.165 |
0.134 |
0.365 |
0.258 |
0.500 |
0.375 |
7.00 |
8.50 |
7.50 |
|
10x6 |
10.750 |
6.625 |
0.134 |
0.109 |
0.165 |
0.134 |
0.365 |
0.280 |
0.500 |
0.432 |
7.00 |
8.50 |
7.63 |
|
10x8 |
10.750 |
8.625 |
0.134 |
0.109 |
0.165 |
0.148 |
0.365 |
0.322 |
0.500 |
0.500 |
7.00 |
8.50 |
8.00 |
|
12x6 |
12.750 |
6.625 |
0.156 |
0.109 |
0.180 |
0.134 |
0.375 |
0.280 |
0.500 |
0.432 |
8.00 |
10.00 |
8.63 |
|
12x8 |
12.750 |
8.625 |
0.156 |
0.109 |
0.180 |
0.148 |
0.375 |
0.322 |
0.500 |
0.500 |
8.00 |
10.00 |
9.00 |
|
12x10 |
12.750 |
10.750 |
0.156 |
0.134 |
0.180 |
0.165 |
0.375 |
0.365 |
0.500 |
0.500 |
8.00 |
10.00 |
9.5 |
