A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9

  • A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
  • A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
  • A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
  • A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
  • A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
Place of Origin CHINA
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number A403 WP347 / WP904L
Minimum Order Quantity 3PCS
Price USD1-60 Per PC
Packaging Details PLY-WOODEN CASE OR PALLET
Payment Terms T/T, L/C, D/A, D/P, Western Union
Supply Ability 9800000PCS PER MONTH
Product Details
Material A403 WP347 / WP904L Technics Butt Weld ,Forged
Place Of Origin China (Mainland) Certifications ISO9001/2008,ISO14001,OHSMS18000
Highlight

butt weld pipe cap

,

stainless steel pipe end caps
Leave a Message
Product Description



A403 WP347 / WP904L  Stainless steel Cap Pipe End Cap 1” To 60” Sch10s To SCH160S ASME B16.9




Product Information
Product Name :Cap, A403 WP347 / WP904L, ANSI B16.9,
Manufacturer : TOBOGROUP



cap,Seamless cap,Steel cap,Carbon Steel Seamless cap,pipe cap,cap end

Based on different materials, pipe caps include carbon steel cap, stainless steel cap, and alloy steel cap etc.
Depending on their construction, pipe caps contain threaded cap, tapered cap and anti-roll cap etc.

Common Shapes:
Pipe caps can be in various shapes. Some of the common shapes are hemispherical, oval, square, rectangular, U shape and I shape.

Size
Pipe cap: 1/2"~60"
DN15~DN1500

Wall Thickness:
sch10, sch20, sch30, std, sch40, sch60, xs, sch80, sch100, sch120, sch140, sch160, xxs, sch5s, sch20s, sch40s, sch80s
Max. wall thickness: 200mm

Materials
Carbon steel: ASTM/ASME A234 WPB-WPC
Alloy steel: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP 911
Stainless steel: ASTM/ASME A403 WP 304-304L-304H-304LN-304N
ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti
ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H
Low temperature steel: ASTM/ASME A402 WPL 3-WPL 6
High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70

Bending, squeezing, pressing, forging, machining and more





stainless steel pipe cap stainless steel pipe cap stainless steel pipe cap

Product name : stainless steel pipe cap
Item : buttweld-Cap
Details :

Pipe Cap Nominal Diameter Pipe Cap Outside Diameter at Bevel Pipe Cap Back to End
DN NPS Series A Series B E T E1
15
 1/2
21.3
18
25
 4.57 25
20
 3/4
26.9
25
25
 3.81 25
25
 1
33.7
32
38
 4.57 38
32
 1.1/4
42.4
38
38
 4.83 38
40
 1.1/2
48.3
45
38
 5.08 38
50
 2
60.3
57
38
 5.59 44
65
 2.1/2
76.1(73)
76
38
 7.11 51
80
 3
88.9
89
51
 7.62 64
90
 3.1/2
101.6
-
64
 8.13 76
100
 4
114.3
108
64
 8.64 76
125
 5
139.7
133
76
 9.65 89
150
 6
168.3
159
89
 10.92 102
200
 8
219.1
219
102
 12.70 127
250
 10
273.0
273
127
 12.70 152
300
 12
323.9
325
152
 12.70 178
350
 14
355.6
377
165
 12.70 191
400
 16
406.4
426
178
 12.70 203
450
 18
457.2
478
203
 12.70 229
500
 20
508.0
529
229
 12.70 254
550
 22
559
-

254

 12.70 254
600
 24
610
630

267

 12.70 305
650
 26
660
-
 267 - -
700
 28
711
720
 267　 - -
750
 30
762
-
 267　 - -
800
 32
813
820
 267 - -
850
 34
864
-
 267 - -
900
 36
914
920
 267 - -
950
 38
965
-
 305 - -
1000
 40
1016
1020
 305 - -
1050
 42
1067
-
 305 - -
1100
 44
1118
1120
 343 - -
1150
 46
1168
-
 343 - -
1200
 48
1220
1220
 343 - -

PS:  When T is less the dimension in parentheses, the height E is available. Otherwise E1 is available.



A403 WP347 / WP904L Stainless Steel Pipe Cap 1” To 60” Sch10s To SCH160S ASME B16.9
