ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting

  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
Place of Origin Shanghai,China
Brand Name TOBO
Certification ISO/TUV/SGS
Model Number Stainless Steel Elbow
Minimum Order Quantity 1PC
Price Negotiable
Packaging Details Standard Shipping Package
Delivery Time 15-30 Workdays
Payment Terms T/T, Western Union
Supply Ability 10 Ton/Month
Product Details
Product Name ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting Form Elbow, Tee, Reducer, Cap, Stub End
Schedules Sch.40 To Sch.XXs Product SS321 ELBOW
Item Shape 90 Degree Elbow Stainless Steel H Beam
Oem Accepted Port Shanghai, Ningbo, Tianjin
Connection Type Threaded Usage Oil Gas Water Industrial
Thickness 0.1-150mm Sizerange 1/2 Inch To 24 Inches
Angle 90 Degrees Degree 45°，90°，180°
Process Forging+machining+heating Treatment Surface Of Finish Pickling Sandblasting Polishing
Leave a Message
Product Description

ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting



1. Product Description

The stainless steel butt welding elbow is a fundamental pipe fitting manufactured for changing pipeline direction in permanent welded systems. Produced from high-quality stainless steel coils and bars through hot pressing or cold forming, it features accurately machined bevel ends that ensure rapid and reliable butt welding. The elbow is suitable for a broad spectrum of operating conditions, including general-purpose, corrosive, and high-temperature services. With clean interior surfaces and precise outer dimensions, this product simplifies alignment, reduces welding time, and delivers long-term service reliability.

2. Product Applications

These elbows serve a wide cross-section of industries where welded piping systems are standard:

  • Industrial piping contractors – general plant piping, equipment hook-ups.

  • HVAC and utilities – chilled water, hot water, steam distribution.

  • Fire protection – wet and dry sprinkler systems.

  • Oil depots and tank farms – product transfer and loading lines.

  • Food ingredient plants – edible oil, syrup, and starch processing.

  • Breweries and distilleries – wort, beer, and spirits routing.

  • Cosmetic manufacturing – lotion, cream, and perfume transfer lines.

  • Mining processing plants – tailings, concentrate, and reagent lines.

  • Cement and building materials – slurry and dust suppression systems.

​3. Product Advantages

  • Ready stock on fast-moving sizes – over 200 sizes kept in inventory for immediate dispatch.

  • Grade flexibility – 304/L for general, 316/L for marine/chemical, higher grades on demand.

  • One-piece forming – no welded seams on the elbow body, eliminating a potential weak point.

  • Consistent end squareness – ensures tight butt joints and reduces stress on welds.

  • Clean bore – free from scale, rust, and burrs, ready for installation upon delivery.

  • Clear markings – easy identification on site, reducing installation errors.

  • Affordable pricing – volume production combined with efficient logistics keeps costs low.

  • Quick quotations – respond to inquiries within 2 working hours.

ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting 0

4.Key Product Parameters

Parameter Details
Primary Grades 304, 304L, 316, 316L (most commonly stocked)
Secondary Grades 321, 347, 309S, 310S, 904L, 2205 (made to order)
Manufacturing Standards ASME B16.9, GB/T 12459, EN 10253-2, JIS B2313
Stock Sizes (Seamless) DN 15 – DN 400 (NPS ½" – 16")
Stock Sizes (Welded) DN 450 – DN 1200 (NPS 18" – 48")
Stock Wall Thickness SCH 10S, 40S, 80S, STD, XS (most common schedules)
Full Range Wall Thickness SCH 5S through SCH 160, including all intermediate schedules
Radius (Stock) Long radius LR (R=1.5D) for all sizes
Radius (On Request) Short radius SR (R=1.0D), 3D, 5D
Angles (Stock) 45°, 90°
Angles (On Request) 30°, 60°, 180°, custom
Bevel Type Single bevel, 30° ±2°, root face 1.6 mm
Surface (Stock) Pickled and passivated
Surface (Optional) Mechanical polish, mirror finish, sandblasted
Standard Tolerances ASME B16.9 Class 1
Quality Checks 100% visual + dimensional; PMI on random samples
Pressure Ratings Class 150, 300, 600, 900, 1500, 2500

FAQ

1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.

2.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.

4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
