Place of Origin: | China |
---|---|
Brand Name: | TOBO |
Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
Model Number: | SS 310S / UNS S31008 / 1.4845 310H / UNS S31009 |
Minimum Order Quantity: | 1PC |
Price: | negotiation |
Packaging Details: | PLY-WOODEN CASE OR PALLET |
Delivery Time: | 15work days |
Payment Terms: | T/T, Western Union, D/P, MoneyGram |
Supply Ability: | 980000000 pcs per month |
Material Grade: | SS 310S / UNS S31008 / 1.4845 310H / UNS S31009 | Standard: | ASME/ANSI B16.9 |
---|---|---|---|
Size: | 1/2’’~48’’(Seamless);16’’~72’’(Welded) | Manufacturing process: | Push, Press, Forge, Cast, etc. |
High Light: | butt welded pipe fittings,industrial pipe fittings |
310H UNS S31009 Butt Weld Tube Fittings Stainless Steel Pipe End Caps
Stainless Steel 310, combining excellent high temperature properties with good weldability and ductility, is designed for high temperature service. SS 310 resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulfur gases are not present. SS 310 is also used for intermittent service at temperatures up to 1040°C.
Stainless Steel 310S is used when the application environment involves moist corrodents in a temperature range lower than that which is normally considered “high temperature” service. The lower carbon content of SS 310S does reduce its high temperature strength compared to 310.
SS 310 | SS 310S | |
Ni | 19 – 22 | 19 – 22 |
Cr | 24 – 26 | 24 – 26 |
C | 0.25 max | 0.08 max |
Fe | Balance | |
Mn | 2 max | 2 max |
Si | 1.50 max | 1.50 max |
S | 0.03 max | 0.03 max |
P | 0.045 max | 0.045 |
Type |
Butt weld fittings elbow ,reducer,tee,stub end ,cap |
Standard |
ASME/ANSI B16.9 |
Size |
1/2’’~48’’(Seamless);16’’~72’’(Welded) |
Wall thickness |
Sch5~Sch160XXS |
Manufacturing process |
Push, Press, Forge, Cast, etc. |
Material |
Carbon steel, stainless steel, alloy steel, duplex stainless, nickel alloy steel |
Carbon steel |
ASTM A234 WPB, WPC; |
Stainless steel |
304/SUS304/UNS S30400/1.4301 304L/UNS S30403/1.4306; 304H/UNS S30409/1.4948; 309S/UNS S30908/1.4833 309H/UNS S30909; 310S/UNS S31008/1.4845; 310H/UNS S31009; 316/UNS S31600/1.4401; 316Ti/UNS S31635/1.4571; 316H/UNS S31609/1.4436; 316L/UNS S31603/1.4404; 316LN/UNS S31653; 317/UNS S31700; 317L/UNS S31703/1.4438; 321/UNS S32100/1.4541; 321H/UNS S32109; 347/UNS S34700/1.4550; 347H/UNS S34709/1.4912; 348/UNS S34800; |
Alloy steel |
ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91; ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65; ASTM A420 WPL3/WPL6/WPL9; |
Duplex steel |
ASTM A182 F51/S31803/1.4462; ASTM A182 F53/S2507/S32750/1.4401; ASTM A182 F55/S32760/1.4501/Zeron 100; 2205/F60/S32205; ASTM A182 F44/S31254/254SMO/1.4547; 17-4PH/S17400/1.4542/SUS630/AISI630; F904L/NO8904/1.4539; 725LN/310MoLN/S31050/1.4466 253MA/S30815/1.4835; |
Nickel alloy steel |
Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN; Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL; Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC; Alloy K-500/Monel K-500/NO5500/2.475; Alloy 600/Inconel 600/NO6600/NS333/2.4816; Alloy 601/Inconel 601/NO6001/2.4851; Alloy 625/Inconel 625/NO6625/NS336/2.4856; Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668; Alloy 800/Incoloy 800/NO8800/1.4876; Alloy 800H/Incoloy 800H/NO8810/1.4958; Alloy 800HT/Incoloy 800HT/NO8811/1.4959; Alloy 825/Incoloy 825/NO8825/2.4858/NS142; Alloy 925/Incoloy 925/NO9925; Hastelloy C/Alloy C/NO6003/2.4869/NS333; Alloy C-276/Hastelloy C-276/N10276/2.4819; Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610; Alloy C-22/Hastelloy C-22/NO6022/2.4602; Alloy C-2000/Hastelloy C-2000/NO6200/2.4675; Alloy B/Hastelloy B/NS321/N10001; Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617; Alloy B-3/Hastelloy B-3/N10675/2.4600; Alloy X/Hastelloy X/NO6002/2.4665; Alloy G-30/Hastelloy G-30/NO6030/2.4603; Alloy X-750/Inconel X-750/NO7750/GH145/2.4669; Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660; Alloy 31/NO8031/1.4562; Alloy 901/NO9901/1.4898; Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926; Inconel 783/UNS R30783; NAS 254NM/NO8367; Monel 30C Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952 Nimonic 263/NO7263 Nimonic 90/UNS NO7090; Incoloy 907/GH907; Nitronic 60/Alloy 218/UNS S21800 |
Package |
Wooden cases, pallets, nylon bags or according to the customers' requirements |
MOQ |
1pcs |
Delivery time |
10-100 days depending on quantity |
Payment terms |
T/T or Western Union or LC |
Shipment |
FOB Tianjin/Shanghai, CFR, CIF, etc |
Application |
Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
Remarks |
Other materials and drawings are available. |
Welcome to contact us.
|
