6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure

  • 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure
  • 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure
  • 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure
  • 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure
  • 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure
Place of Origin China
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number 6Mo 31254
Minimum Order Quantity 1PC
Price negotiation
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 15 work days
Payment Terms T/T, D/P, D/A, Western Union
Supply Ability 9800000PCS Per month
Product Details
Product Name Stainless Steel Bend Standard ANSI/ASME , EN, DIN,JIS,GOST Etc.
Type Bend Elbow Application Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding Etc
Technology Forged, Pressure SCH5 To SCH160
Connection Welding Radius 2D 3D 5D
Highlight

Pipe Fittings Elbow

,

Butt Welding Elbow
Leave a Message
Product Description

6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure





Quick Details

Material:
Stainless Steel
 Technics:
Forged
 Type:
Elbow
Place of Origin:
Shanghai, China (Mainland)
 Brand Name: TOBO Connection:
Welding
Shape:
Equal
 Head Code:
ROUND
 STANDARD:
ANSI/ASME , EN, DIN,JIS,GOST etc.

Packaging & Delivery

Packaging Details: Fumigation-free Plywood or Wooden Case Packing/ Pallet Packing/ other packing suitably protected for sea-worthly delivery or as requested.
Delivery Detail: 20 DAYS



Product Description


Product Name:     254SMo 31254 stainless steel elbow 45 degree  /90 deg elbow  ASME B16.9

Other pipe fitting Include Butt welded stianless steel elbow,Con. reducer,Ecc. Reducer,Tee,Stub end
Size Range:
DN15-DN600  (1/2"-24")       Seamless Type
DN15 - DN1200 (1/2"- 48" )  Welded type
Wall Thickness: SCH5 to SCH160
Material:
Carbon Steel: ASTM A234 WPB, WPC, ASTM A420 WPL1, WPL3, WPL6 etc
Stainless Steel: ASTM A403 WP304/304L, WP316/316/L, WP317L, WP321, WP347 & WPS31254
Alloy Steel: ASTM A234 WP1/WP12/WP11/WP22/WP5/WP7/WP9/WP91
Duplex and super duplex steel: ASTM A815 UNS S31803/S32205/S32750/S32760
Manufacture Standard:
ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN 2606 ,DIN2615,DIN2616 ,BG12459-90,GB/T13401,HGJ514 ,SH3408  ,SH3409, HG/T21635, HG/T21631,
End Bevel: According to the standard or the customer's requirements
Surface Treatment: Shot blasted, rust-proof black oil
Non-destructive testing: penetration test, ultrasonic test, radiographic test, any third parties inspection,





Packaging & Shipping

Fumigation-free Plywood or Wooden Case Packing/ Pallet Packing/ other packing suitably protected for sea-worthly delivery or as requested.



Application

 Electric power industry, petroleum industry, nuclear power industry, petrochemical industry, oil and gas industry, ship-making  industry, chemical industry, pharmaceutical industry, papermaking industry, building construction industry

 6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure6MO 31254 Stainless Steel Elbow Pipe Steel 90 Degree Elbow SCH5 To SCH160 Pressure



Alloys 254 / 254 SMO / 6 Mo is an austenitic stainless steel with a high molybdenum content. Coupled with Nickel and Copper this gives the alloy a good resistance to pitting and crevice corrosion, especially in environments containing halide ions, e.g. chloride, bromide and fluoride solutions.
254 SMO (UNS S31254) may offer a cost effective solution to Nickel and Titanium alloys in these environments.


Alloy Common Name Related Specifications Tensile Strength Proof Stress Elongation
British European United States
Alloy 254 254SMO   1.4547 ASTM A479/A473,
/A240 S31254
F44		 655
[95]		 305
[44.2]		 35

Alloy 254 Technical Information

Alloy 254 Bar stock sizes available
Diameter
(in)		 Diameter
(mm)		 kg per m
3/8 9.53 0.57
1/2 12.70 1.01
5/8 15.88 1.58
3/4 19.05 2.28
7/8 22.23 3.10
1 25.40 4.05
1 1/4 31.75 6.33
1 3/8 31.75 6.33
1 1/2 34.93 7.66
1 3/4 44.45 12.41
2 50.80 16.21
2.36 60 22.62
2.56 65 26.55
2.76 70 30.79
2.95 75 35.34
3.15 85 40.21
3.54 90 50.89
3.94 100 62.83
4.33 110 76.03
4.72 120 90.48
5.12 130 106.19
6.10 155 150.95
Specifications of Alloy 254
  • Alloy 254 to MLA-MPS-254-BAR
  • ASTM A479 Bar UNS S31254
  • ASTM A276 Bar UNS S31254
  • ASTM A182 Forgings UNS S31254 F44
  • ASTM A240 Plate S31254

Downloads
Purchase Specifications >
  • Alloy 254 Bar Purchase Specification
