2 Inch Butt Weld Fittings Stainless Steel Caps DIN 2605 UNS S32750 3" Sch80s
| Place of Origin | China |
|---|---|
| Brand Name | Tobo |
| Certification | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number | Cap |
| Minimum Order Quantity | 1pcs |
| Price | USD Depending on quantity |
| Packaging Details | PLY-WOODEN CASE OR PALLET |
| Delivery Time | 10-100 days depending on quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3,0000pcs per month |
Product Details
| Product Name | Stainless Steel Elbow | Material Grrade | UNS S32750 |
|---|---|---|---|
| Size | 1-48 Inch | ||
| Highlight | butt weld tube fittings,butt welded pipe fittings |
||
Product Description
2 Inch Butt Weld Fittings Stainless Steel Caps DIN 2605 UNS S32750 3" Sch80s
|
Product Details |
|
|
Product name
|
Stainless steel pipe fitting |
|
Brand name
|
Tobo |
|
Standard
|
DIN2605,DIN2615,DIN2616,DIN2633 |
|
Material
|
304, 316L, 321, 310S, 1.4301, 1.4307, 1.4404, S31803, S32750, 904L, Monel 400, Inconel 800 |
|
Surface
|
Pickling and bright |
|
Certificate
|
DNV, BV, LR, GL, NK, RMRS |
|
Packing
|
In wooden cases |
|
Shipment
|
By sea, by air, by express |
|
Specifications |
|
Chemical Composition(%) |
|||||||||||
|
Grade |
C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu | |
|
201 |
≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.060 | ≤0.03 |
16.00~ 18.00 |
3.5~5.5 | - | - | 0.08 | 1.5 |
| 202 | ≤0.15 | ≤1.00 | 7.5~10.00 | ≤0.060 | ≤0.03 |
17.00~ 19.00 |
4.0~6.0 |
- | ≤0.25 | ||
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
16.00~ 18.00 |
6.00~8.00 | - | |||
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 |
17.00~ 19.00 |
8.00~10.00 | - | |||
| 304 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
18.00~ 20.00 |
8.00~10.50 | - | |||
| 304L | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
18.00~ 20.00 |
9.00~13.00 | - | |||
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
24.00~ 26.00 |
19.00~22.00 | - | |||
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
16.00~ 18.00 |
10.00~14.00 | 2.00~3.00 | |||
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
16.00~ 18.00 |
12.00~15.00 | 2.00~3.00 | |||
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 |
17.00~ 19.00 |
9.00~13.00 | - | |||
|
430 |
≤0.12 | ≤0.75 | ≤1.00 | ≤0.040 | ≤0.03 |
16.00~ 18.00 |
|
- | |||
| 2205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.030 | ≤0.015 |
22.00~ 23.00 |
4.5~6.5 | 2.5~3.5 | |||
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | ≤0.035 | ≤0.015 |
24.00~ 26.00 |
6.00~8.00 | 3.0~5.0 | |||
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 |
19.00~ 23.00 |
23.00~28.00 | 4.0~5.0 |
1.0~2.0 |
||
|
INCONEL 028 |
≤0.03 | ≤1.00 | ≤2.50 | ≤0.030 | ≤0.030 | ≤28.0 | ≤34.0 | ≤4.0 | ≤1.4 | ||
|
MONEL 400 |
≤0.30 | ≤0.5 | ≤2.00 | - | ≤0.024 | - | ≥63.0 | - | ≤34.0 | ||
|
INCONEL 800 |
≤0.10 | ≤1.00 | ≤1.50 | - | ≤0.015 | ≤23.0 | ≤35 | 4.0~5.0 | - | ≤0.75 |
Ti≤0.6 Al≤0.6 |
