TOBO GROUP
TOBO International Trading(Shanghia)Co.,Ltd Tianda Oil Pipe Co., Ltd
TOBO Pipeline Equipment Co.,Ltd TPCO & TISCO Pipe(Tianjin)Co.,Ltd.
| Place of Origin: | China/Japan/Germany |
|---|---|
| Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification: | ISO/PED/TUV/SGS/LR/BV |
| Model Number: | TP310 / TP347 / TP321H |
| Minimum Order Quantity: | 0.5-1 tons |
| Price: | negotiable |
| Packaging Details: | in plastic bags then in bundles |
| Delivery Time: | According to the qty |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1500 tons per month |
| SIZES: | 1/8"NB - 24 "NB | Material: | TP310 / TP347 / TP321H |
|---|---|---|---|
| Color: | White Silver Gold | Standard: | TP310 / TP347 / TP321H Seamless Stainless Steel Pipe With Butt Weld Ends |
| Highlight: | marine stainless steel tubing,seamless stainless steel tube |
||
TP310 / TP347 / TP321H Stainless Steel Seamless Tube With Butt Weld Ends
| Brand Name: | TOBO |
| Model Number: | TP310/TP347/TP321/TP304H |
| Certification: | ISO, GOS, PED |
| Place of Origin: | China |
| Product Name | Seamless Stainless Steel Pipe | Product Type | TP310 / TP347 / TP321H Seamless Stainless Steel Pipe |
| Size | 1-48 inch | DN15-DN1200 | 15-1200 |
| Material Grade | TP310/TP347/TP321/TP304H | Type | Seamless or weld |
| Standard | ASME B16.9 | Standard | DIN,EN,ASTM,BS,JIS,GB,etc. |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc | ||
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 3,0000pcs per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
Quick Detail:
ASTM A312/DIN17456/JIS G3459 stainless steel seamless pipe, cold drawn/cold rolled
ASTM A312/A213 TP310,TP310S,TP347,TP347H,TP321H seamless pipe / tubing with butt weld ends
SIZE RANGE:
| STEEL TYPES | SIZE RANGE |
| Stainless steel seamless pipe&tube | OD: 6-830mm WT: 0.6-60mm |
| U-Tube | OD: 12-38mm WT: 0.6-4mm |
MAIN STEEL TYPE AND GRADE :
| PRODUCTS | TYPICAL STEEL GRADE |
| Austenitic | TP304,TP304L,TP304H,TP316,TP316L,TP316H,TP316Ti |
| Duplex / Super Duplex | S31803, S32205, S32750 |
MAIN PRODUCTION STANDARDS:
| STANDARD TYPE | STANDARD |
| EN | EN10216-5 , EN10216-2 |
| DIN | DIN 17456 , DIN 17458 |
| ASTM | ASTM A312, A213, A269, A511, A789, A790 ETC |
| GOST | GOST 9941 , GOST 5632 |
| JIS | JIS G3459 , JIS G3463 |
| GB | GB/T14975,GB/T14975, GB13296, GB5310, GB9948 |
Stainless Steel Seamless Pipe:
1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include “Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
8.MTC: BWSS Official Original MTC paper will be supplied for each order.
Standard Specification:
ASTM A213 / A213M - 11a:Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A269 - 10:Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A312 / A312M - 12:Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A511 / A511M - 12:Standard Specification for Seamless Stainless Steel Mechanical Tubing
ASTM A789 / A789M - 10a:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
ASTM A790 / A790M - 11:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
DIN 17456-2010:GENERAL PUROSE SEAMLESS CIRCULAR STAINLESS STEEL TUBES.
DIN 17458-2010:Seamless Circular of Austenitic Stainless Steel Tube
EN10216-5 CT 1/2 : Stainless Steel Seamless Pipe & Tube
GOST 9941-81:SEAMLESS COLD- AND WARM-WORKED TUBES MADE OF CORROSION RESISTANT STEEL.
Others like BS, JIS standard or can supply
Description:
| Mechanical Property | Material Item | 304 | 304L | 304 | 316L | Top Technology |
| Tensile Strength | ≥520 | ≥485 | ≥520 | ≥485 | ||
| Yield Strength | ≥205 | ≥170 | ≥205 | ≥170 | ||
| Extension | ≥35% | ≥35% | ≥35% | ≥35% | ||
| Hardness (HV) | <90 | <90 | <90 | <90 |
