Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc

  • Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
  • Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
  • Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
  • Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
  • Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
Place of Origin China
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number A-105
Minimum Order Quantity 1pc
Price US $ 10 - 100 / Kilogram
Packaging Details Seaworthy wooden cases or pallets tied by steel band or as per client's requirements
Delivery Time 30 days After Receiving the 30% Prepayment by T/T or LC
Payment Terms L/C, T/T, Western Union
Supply Ability 50 Metric Ton/Metric Tons per Month
Product Details
Disc Type Scored Reverse Domed Size 150mm
Bursting Pressure 0.05~10 Mpa Operation Pressure 90% Max
Pplicable For Medium Pressure(Gas, Liquid, Dust) Tolerance +/- 10%
MOQ 1pcs Delivery Time 10-100 Days Depending On Quantity
Payment Terms L/C,T/T Shipment FOB Tianjin/Shanghai, CFR, CIF Etc
Remarks Other Materials And Drawings Are Available.
Highlight

forged fittings and flanges

,

butt weld flanges
Leave a Message
Product Description

Monel Stainless Steel 316 Double Layer Scored Reverse Domed Bursting Disk Rupture Disc

Quick Details

Place of Origin:
Shanghai, China (Mainland)
 Brand Name: TOBO Model Number:
ST
Material:
stainless steel,monel,copper,nickel
 Disc Type:
Reverse Domed
 Size:
25mm ~ 300mm
Discharge diameter:
150mm
 Load Type:
Tension
 Applicable for:
Gas, Liquid, Dust
Bursting Pressure:
0.05~10 Mpa
 Operation Pressure:
90% max.

Packaging & Delivery

Packaging Details: carton
Delivery Detail: 30days

Sawteeth stainless steel monel reverse domed bursting disc



The bursting disc is in the non closure pressure preset pressure accurate motion.Bursting disc discharge instantly put a container of excess pressure in the presetpressure and temperature, the effective protection of pressure vessels, piping system. It has the advantages of good sealing, discharge of large area, high accuracy, corrosion resistance, reliable working etc..



Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc



  • Materials can be in:



Stainless Steel
Nickel
Aluminium
Monel
Inconel
Hastelloy
Tantalum
Titanium

  • Features:

Double-layer
Reverse acting
Full vacuum resistance
Full vent area
Fragmentation-free
Installation upstream ety valves
Smooth process side
Corrosion resistant
Very high lifetime
Suitable for pulsating pressures
Diffusion-free sealing
Sanitary design

  • Specifications:



Disc Type Scored Reverse Domed
Size 25mm ~ 300mm
Discharge diameter 150mm
Bursting Pressure 0.05~10 Mpa
Operation Pressure 90% max.
Applicable for Medium Pressure(Gas, Liquid, Dust)
Tolerance +/- 10%



  • Disc Holder
  •

Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc



Monel Double Layer Scored Reverse Domed Bursting Disk Rupture Disc
