Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch

  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
  • Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
Place of Origin China
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number Elbow
Minimum Order Quantity 1PC
Price USD Depending on quantity
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 10-100 days depending on quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3,0000pcs per month
Product Details
Size 1-48 Inch Material Grrade WP304
Standard ASME B16.9 Type Seamless Or Weld
Connection Welding Shape Equal
Highlight

Pipe Fittings Elbow

,

Stainless Steel 90 Degree Elbow
Leave a Message
Product Description

Stainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch

Specifications

Types:90/180 degreestainless steel elbow.
Material:stainless steel(S31803 S32750 S32760)

Product Name:

stainless steel 90 degree 4 inch elbow





1) Types: Elbow 90o, LR/SR, 180o LR/SR, elbow

45o LR, equal tee, reducing tee. Stainless Steel Tee. Stainless Steel Reducer Tube

2) Wall thickness: Schedule 5 through XXS

3) Materials: Stainless steel

4) Standards: ANSI, DIN, JIS, ASME, ASTM, MSS and EN

5) Size: 1/2" ~ 48" (DN15mm ~ 1, 200mm)





Product Name: UNS S32750 UNS S32205 UNS S31803 pipe fittings Tee / Red / ELB

Size Range:
DN15-DN600 (1/2"-24") Seamless Type
DN15 - DN1200 (1/2"- 48" ) Welded type
Wall Thickness: SCH5 to SCH160
Material:
Carbon Steel: ASTM A234 WPB, WPC, ASTM A420 WPL1, WPL3, WPL6 etc
Stainless Steel: ASTM A403 WP304/304L, WP316/316/L, WP317L, WP321, WP347 & WPS31254
Alloy Steel: ASTM A234 WP1/WP12/WP11/WP22/WP5/WP7/WP9/WP91
Duplex and super duplex steel: ASTM A815 UNS S31803/S32205/S32750/S32760
Manufacture Standard:
ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN 2606 ,DIN2615,DIN2616 ,BG12459-90,GB/T13401,HGJ514 ,SH3408 ,SH3409, HG/T21635, HG/T21631,
End Bevel: According to the standard or the customer's requirements

Surface Treatment: Shot blasted, rust-proof black oil
Non-destructive testing: penetration test, ultrasonic test, radiographic test, any third parties inspection

Nominal Pipe Size (NPS) Outside Diameter Center-to-Center,O Back-to-Face,K
mm Inch
1/2 21.3 0.84 76 48
3/4 26.7 1.05 76 51
1 33.4 1.32 76 56
11/4 42.2 1.66 95 70
11/2 48.3 1.90 114 83
2 60.3 2.38 152 106
21/2 73.0 2.88 190 132
3 88.9 3.50 229 159
31/2 101.6 4.00 267 184
4 114.3 4.50 305 210
5 141.3 5.56 381 262
6 168.3 6.62 457 313
8 219.1 8.62 610 414
10 273.0 10.75 762 518
12 232.8 12.75 914 619
14 355.6 14.00 1067 711
16 406.4 16.00 1219 813
18 457.0 18.00 1372 914
20 508.0 20.00 1524 1016
22 555.9 22.00 1676 1118
24 610.0 24.00 1829 1219





Our advantage



i. Ultrasonic equipment for thickness inspection

ii. Ultrasonic flaw detecting equipment

iii. Universal material testing equipment

iv. Carbon and sulfur analyzerStainless Steel Elbow 310S 316L 904L 2205 304 Long / Short Radius Size 1-48 inch
