S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine

  • S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine
  • S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine
  • S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine
  • S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number Duplex Stainless Steel Pipe
Minimum Order Quantity 500KG
Price USD Depending on quantity
Packaging Details PLY-WOODEN CASE OR PALLET
Delivery Time 10-90 work days
Payment Terms L/C, T/T, Western Union
Supply Ability 500 tons per month
Product Details
Material S32101,S32205,S31803,S32304,S32750, S32760 Thickness 2.5mm---50mm
Type ASME A789 A790 A450 A530 Standard ASTM A790/A789 PICKLED AND ANEANLED
OD 6MM---710MM
Highlight

duplex ss pipe

,

thin wall stainless steel tubing
Leave a Message
Product Description

Duplex Stainless Steel Pipe S32750ASME A789 A790 A450 A530 Size 1-48 inch







Our TOBO offer an extensive range of Seamless Pipes to our clients. We also deal with super duplex pipes. Our stainless steel seamless pipe was width used in Mining, Energy, Petrochemical, Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc



1 Standard: ASTM A790/A789 PICKLED AND ANEANLED

2 Material: S31803/S31500/S32750 etc

3 OD: 6MM---710MM

Thickness: 2.5mm---50mm

4 Certificate: PED, ISO, GB, GOST

5 Producing method: cold drawn and cold rolled



Stainless Steel Pipe:


1. Material: S31803/S31500/S32750 ETC
2. O.D: 6mm-710mm , Thickness:2.5-50mm

3. A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the Thpe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.

4. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.

5. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the lenss than the permitted in Section 9 of Specification A999/A999M

6. Butt Weld End: According to ANSI B 16.25
7. Pipe Marking: Specified in A999/999M, include “Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”

8. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.

9. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.

10. MTC: TOBO Official Original MTC paper will be supplied for each order.



We can dealing with a wide range material as following:



Material Grade:



American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...
Europen Standard 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501
Russia Standard 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ







Inspection & Test
1. 100% PMI, Spectro Chemical Analysis Test for Raw Material
2. 100% Dimension & Visual Examination
3. Mechanical Properties Test Include Tension Test Flattening Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test
4. 100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT)
5. Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor)
6. Straightness Test (optional)
7. Roughness Test (optional)
8. Intergranular Corrosion Test(optional)
9. Impact Test (optional)
10. Grain Size Determinations (optional)
NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION.



S32750ASME A789 A790 Duplex Stainless Steel Pipe 6MM---710MM OD For Machine
