Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment

  • Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment
  • Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment
  • Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment
  • Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment
Place of Origin CHINA
Brand Name TOBO
Certification SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number Cu-Ni 90-10
Minimum Order Quantity 0.5-1 tons
Price negotiable
Packaging Details in plastic bags then in bundles
Delivery Time According to the qty
Payment Terms T/T, L/C, Western Union,
Supply Ability 6000TONS/MONTH
Product Details
Standard Copper Nickel Flanges Cu-Ni 90-10 Color White Silver Gold
Types White,Black,Yellow,Galvanized Material Grade Cu-Ni 90-10
Outer Diameter 1/2'~100'
Highlight

forged fittings and flanges

,

butt weld flanges
Leave a Message
Product Description

Copper Nickel Flanges Cu-Ni 90-10 #150 WN Copper Nickel Flanges FF



Place of Origin CHINA Powder Or Not Not Powder
Application Steam air gas oil pipes or oth Model Number DWNF040
Material: Nickel Colour White,Black,Yellow,Galvanized



Packaging & Delivery

Packaging Details: Packing of copper nickel flange: Plastic bags and foam paper as inside,Wooden case as outside, or according to you requirement.

Delivery Detail: 5-20 days

Specifications

copper nickel flange
material:carbon steel
size:1/2'~100'
standard:ASME DIN JIS
certificates;API ISO BV ABS



copper nickel flange

Our flanges feature high strength,good toughness,and high reistance to corrosion,

high pressure and temperature.The raw materials

of them come into carbon steel,stainless steel,alloy steel,low temperature steel

and high performance steel.Also,we can provide customized flanges according to customers'requirements.





Type

Flange

flange is a type of industrial flange designed to transfer stresses to

the pipe to reduce high stress concentrations at the base of the flange.

Compared with other types,weld neck ,slip on ,blind,plate etc.
Size Weld neck flange: 1/2"~100"
DN10~DN4000
Pressure

American Series: CLASS 150, CLASS 300, CLASS 400, CLASS 600,

CLASS 900, CLASS 1500, CLASS 2500
European Series: PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63,

PN 100, PN 160, PN 250, PN 320, PN 400
Standards

GB/T9112-2000
GB/T9115.1-2000 GB/T9115.2-2000 GB/T9115.3-2000 GB/T9115.4-2000
GB/T9124-2000
GB/T13402-1992
SH/T3406-1996
GD2000 GD87-1101
JB/T74-1994
JB/T75-1994
JB/T82.1-1994 JB/T82.2-1994 JB/T82.3-1994 JB/T82.4-1994
HG/T20592-2009 HG/T20614-2009
HG/T20615-2009 HG/T20623-2009 HG/T20635-2009
ASME B16.5-2009 ASME B16.47-2006
API605-1988
MSS SP 44-2006
CSA Z245.12-05-2005
EN1092-1-2007 EN1759-1-2004
DIN2630 DIN2631 DIN2632 DIN2633 DIN2634 DIN2635 DIN2636

DIN2637 DIN2638
BS1560-3.1-1989 BS4504-3.1-1989
AFNOR NF E29-200-1-2007
ISO7005-1-1992
AS2129-2000
JIS B2220-2004
Material

Carbon steel: A105
Alloy steel: A182 F 1-F 2-F 5-F 9-F 10-F 91-F 92-F 122-F 911-F 11-F 12-F 21-F 22
Stainless steel: A182 304-304H-304L-304N-304LN 316-316H-316L

-316N-316LN 321-321H 347-347H
Low temperature steel: A522 A707 Grade L 1-L 2-L 3-L 4-L 5-L 6-L 7-L 8
High performance steel: A694 F 42-F 46-F 48-F 50-F 52-F 56-F 60-F 65-F 70

Low-temperature steel: ASTM/ASME A402 WPL 3-WPL 6
High performance: ASTM/ASME A860 WPHY 42-46-52-60-65-70
Surface treatment Transparent oil, rust-proof black oil or hot galvanized
Flange Facing Types

American Series: Flat Face(FF), Raised Face(RF), Tongue(T), Groove(G),

Female(F), Male(M), Ring Joints Face(RJ)
European Series: Type A(Flat Face), Type B(Raised Face), Type C(Tongue),

Type D(Groove), Type E(Spigot), Type F(Recess), Type G(O-Ring Spigot),

Type H (O-Ring Groove)
Industries Served

Electrical power, petroleum, natural gas, chemical, shipbuilding,

heating, papermaking, metallurgy
Packing wooden case, pallet or as customers' requirement
Min order 1 piece
Delivery time 7 after receipt of advanced payment
Certification API, CCS, and ISO9001:2000




 Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment

Silver / Gold Color Slip On Welding Steel Pipe Flanges With Transparent Oil Surface Treatment
