Food Grade Sanitary Stainless Steel Tee Fitting

Food Grade Sanitary Stainless Steel Tee Fitting

This food grade sanitary stainless steel tee fitting is engineered for hygienic fluid transfer in processing lines where cleanliness and product safety are non-negotiable. Manufactured from ASTM A270 / A312 SS304 and SS316L with a fully descaled and passivated bore, the tee delivers a smooth, crevice-free interior that resists bacterial adhesion and meets 3A Sanitary Standards for dairy, beverage and pharmaceutical applications.

Every sanitary stainless steel tee is formed from certified mill test report (MTR) material, orbitally welded where required, and finished with an internal surface roughness of Ra 0.4-0.8 μm. The result is a fitting that cleans in place (CIP) and sterilizes in place (SIP) reliably, reducing downtime and extending service intervals on your production line.

Product Parameters

Key Advantages

• Food grade SS316L with low carbon content prevents intergranular corrosion after welding.
• Crevice-free mirror polished bore supports CIP/SIP hygiene protocols.
• Certified to 3A Sanitary Standards and available with full material traceability.
• Self-draining geometry reduces product hold-up and cross-contamination risk.
• Supplied with surface finish and weld-end preparation suitable for orbital welding.

Applications

• Dairy and beverage processing pipelines.
• Pharmaceutical and biotech clean-in-place systems.
• Cosmetics and personal care product transfer lines.
• Food and brewery sanitary distribution systems.

FAQ

Q: Is this food grade sanitary tee suitable for CIP systems?
A: Yes. The mirror polished internal surface and self-draining design make it ideal for clean-in-place and sterilize-in-place applications, with Ra 0.4-0.8 μm finish that minimizes residue retention.

Q: Which material should I choose for a dairy line?
A: SS316L is recommended for dairy and other chloride-containing environments because its low carbon content improves weld integrity and resists pitting corrosion.

Q: Can you provide the sanitary tee in reducing sizes?
A: Yes, equal and reducing configurations are available from 1/2" to 4", and custom branch reductions can be manufactured to your line specification.

Manufacturing & Quality Control

The sanitary tee is produced from certified ASTM A270 and A312 material with full mill test reports. After forming, each fitting is solution annealed and passivated to remove free iron and restore a uniform chromium oxide passive layer that protects the polished surface. Electropolishing to Ra 0.25 μm is available on request for ultra-hygienic pharmaceutical applications, and every piece is individually wrapped to preserve finish during shipment.

• Full material traceability with EN 10204 3.1 certificates.
• 100% dimensional inspection and hydrostatic pressure testing.
• Surface roughness verified with a profilometer to Ra 0.4-0.8 μm.
• Clean-room grade packaging protects the polished bore.

More Questions

Q: Can this tee be electropolished for pharmaceutical use?
A: Yes, we offer electropolishing to Ra 0.25 μm or better, which further improves cleanability and corrosion resistance for pharmaceutical and biotech systems.
