API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction

  • API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction
  • API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction
  • API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction
  • API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction
Place of Origin China/Japan/Germany
Brand Name TOBO/TPCO/TISCO/VALIN/METAL
Certification ISO/PED/TUV/SGS/LR/BV
Model Number API 5L
Minimum Order Quantity 1 Ton
Price USD Depending on length
Packaging Details WOODEN CASE
Delivery Time 10- 100 work days
Payment Terms L/C, T/T, Western Union
Supply Ability 200 tons per week
Product Details
Size 1/8-72” Material API 5L Grade A &B
OD 1-600mm Thickness 1-100mm
Standard ANIS B36.10~B36.19 Type Duplex Stainless Pipe
Highlight

API 5L Line Pipe

,

API Seamless Pipe
Leave a Message
Product Description

API Carbon Steel Pipe API 5L Gr.B Sch40 erw carbon steel pipe Size 1/8-72”inch



ERW steel pipe means Electric Resistance Welded Pipes. ERW pipes are used for many different applications, as it is the most readily available and economical type of mechanical tubing. ERW pipe initially starts out as a flat pieces of steel, and then rolled into a tube shape. Without overlapping, the seam is then welded using a process called "Electric Resistance". During the process of creating ERW tubing, the piping may either be hot rolled or cold rolled, which has a drastic change on the outcome of electric resistance piping.





API 5L Gr.B Sch40 erw carbon steel pipe
Out Diameter 26.9-340mm
Thickmess 1.0-12mm
Length 5.8-12m , according to customers' requirements
International Standard ISO 9001;2000
Standard ASTM A 53 / API 5L /A 671/A 672
Material Q195/Q215/Q235/Q345
Technique: Welded
Packing In bundles or according to customers' requirements
Usage

1.For low pressure liquid delivery such as water , gas and oil

2.For construction
Main market: Middle east, Africa, North and South America, East and West Europe, South and Southeast Asia,Australia
Place of Origin China
Productivity 10000Ton/Month
Remarks

1)Payment term : T/T,L/C

2)Trade Terms : FOB / CFR /CIF/CNF

3)Minimum quantity of order : 20 MT (20,000KGS)

4)Delivery period : 10 to 35 Days .





OD Weight/pc
inch mm SCH10 SCH20 SCH30 STD SCH40 SCH60 XS
4" 114.3 3.05   4.78 6.02 6.02   8.56
5" 141.3 3.4     6.55 6.55   9.53
6" 168.3 3.4     7.11 7.11   10.97
8" 219.1 3.76 6.35 7.04 8.18 8.18 10.31 12.7
10" 273 4.19 6.35 7.8 9.27 9.27 12.7 12.7
12" 323.8 4.57 6.35 8.38 9.53 10.31 14.27 12.7
14" 355.6 6.35 7.92 9.53 9.53 11.13 15.09 12.7
16" 406.4 6.35 7.92 9.53 9.53 12.7 16.66 12.7
18" 457.2 6.35 7.92 11.13 9.53 14.27 19.05 12.7
20" 508 6.35 9.53 12.7 9.53 15.09 20.62 12.7
22" 558.8 6.35 9.53 12.7 9.53   22.23 12.7
24" 609.6 6.35 9.53 14.27 9.53 17.48 24.61 12.7
26" 660.4 7.92 12.7   9.53     12.7



Size tolerance

a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm



API 5L Gr.B Sch40 Erw API Carbon Steel Pipe Size 1/8-72” Inch For Construction
