4'' STD UNS S20910 And XM-19 Austenitic Stainless Steel Pipe Corrosion Resistance

Basic Information

Brand Name:	TOBO
Model Number:	xm-19

Minimum Order Quantity:	5PCS
Packaging Details:	Wooden box or wooden pallet
Delivery Time:	15 days
Payment Terms:	T/T, Western Union
Supply Ability:	50,000 pcs/month

Get Best Price Contact Now

Application:	Fluid Pipe	Alloy Or Not:	Is Alloy
Technique:	Cold Rolled	Thickness:	1 - 30 Mm,2 - 60 Mm
Surface Treatment:	BA	Section Shape:	Round
Outer Diameter(round):	6 - 710 Mm	Standard:	ASTM,DIN,GB,JIS
Highlight:	UNS S20910 Stainless Steel Pipe , XM-19 Austenitic Stainless Steel Pipe , Austenitic Stainless Steel Fluid Pipe

4'' STD Stainless Steel UNS S20910 and XM-19 Austenitic Stainless Steel with a Blend of Strength and Corrosion Resistance

Detailed Information

NITRONIC 50 (XM-19) (UNS S20910):

NITRONIC 50 Stainless Steel provides a combination of corrosion resistance and strength not found in any other commercial material available in its price range. This austenitic stainless has corrosion resistance greater than that provided by Types 316 and 316L, plus approximately twice the yield strength at room temperature. In addition, Armco NITRONIC 50 Stainless has very good mechanical properties at both elevated and sub-zero temperatures. And, unlike many austenitic stainless steels, NITRONIC 50 does not become magnetic when cold worked.

Annealing Temperature

NITRONIC 50 Stainless Steel can be supplied annealed at 1950 F to 2050 F (1066 C to 1121 C). For most applications, the 1950 F (1066 C) condition should be selected, as it provides a higher level of mechanical properties along with excellent corrosion resistance. When as-welded material is to be used in strongly corrosive media, the 2050 F (1121 C) condition should be specified in order to minimize the possibility of intergranular attack.

Alloy minimum mechanical properties in the room temperature:
Grade	XM-19
Tensile Strength (Mpa)	690
Yield Strength (Mpa)	380
Elongation (%)	35
Hardness HB	≤241
Features	High strength austenitic alloy Good corrosion resistance
Applications	Seawater pump shafts Heat exchangers Pressure vessels Marine hardware

ALLOY 400 DIN W. NR. 2.4360,2.4361
SPECIFICATIONS
Form	ASTM
Rod, bar and shape	B164
Plate, sheet and strip	B127, B906
Seamless and Welded pipe	B165, B829
Welded pipe	B725, B775
Welded tube	B730, B751
Fitting	B366
Forging	B564

PHYSICAL PROPERTIES
Density	7.8g/cm3
Melting Range	1415-145℃

4'' STD UNS S20910 And XM-19 Austenitic Stainless Steel Pipe Corrosion Resistance 0
