ASTM B 829 Thick Wall Steel Pipe ASME SB 407 ASME SB 829 Incoloy 800H / 800HT / 800AT
| Place of Origin | China/Japan/Germany |
|---|---|
| Brand Name | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification | ISO/PED/TUV/SGS/LR/BV |
| Model Number | SN20140404090919553 |
| Minimum Order Quantity | 0.5-1 tons |
| Price | negotiable |
| Packaging Details | in plastic bags then in bundles |
| Delivery Time | According to the qty |
| Payment Terms | T/T, L/C, Western Union, MoneyGram |
| Supply Ability | 6000TONS/MONTH |
Product Details
| Standard | ASTM B 163 & ASME SB 163 ASTM B 407 ASTM B 829 ASME SB 407 | Color | White Silver Gold |
|---|---|---|---|
| Types | Nickel Alloy Pipe | Outer Diameter | 4mm OD To 219mm OD |
| Highlight | Thin Wall Steel Pipe,Steel Round Pipe |
||
Product Description
ASTM B 163 & ASME SB 163 ASTM B 407 ASTM B 829 ASME SB 407 ASME SB 829 Incoloy 800H/ 800HT / 800AT Nickel Alloy Pipes
Incoloy Alloy 800H/800HT/800AT
Incoloy 800, Alloy 800, Ferrochronin 800, Nickelvac 800, Nicrofer 3220.
Common Trade Names: Incoloy 800H/800HT/800AT, Alloy 800H/800HT/800AT, Ferrochronin 800H/800HT/800AT, Nickelvac 800H/800HT/800AT, Nicrofer 3220.
INCOLOY alloy 800H/800HT/800AT is designated as UNS N08810, UNS N08811 and Werkstoff Number 1.4876, 1.4958, 1.4959. It is listed in NACE MR0175 for oil and gas service.
Nickel-iron-chromium alloys having the same basic composition as INCOLOY alloy 800 but with significantly higher creep-rupture strength. The higher strength results from close control of the carbon, aluminum, and titanium contents in conjunction with a high-temperature anneal. Used in chemical and petrochemical processing, in power plants for super-heater and reheater tubing, in industrial furnaces, and for heattreating equipment.
Specifications
INCOLOY alloy 800H/800HT/800AT is designated as UNS N08810, UNS N08811 and Werkstoff Number 1.4876, 1.4958, 1.4959. It is listed in NACE MR0175 for oil and gas service.
Rod, Bar, Wire, Forgings, and Forging Stock: ASTM B 408, ASME SB 408 (Rod & Bar), ASTM B 564, ASME SB 564 (Forgings), ASME Code Case 1325 (All Product Forms), ASME Code Case 1949 (Forgings), AMS 5766 (Rod & Bar), ISO 9723 (Rod & Bar), ISO 9724 (Wire), ISO 9725 (Forgings), BS 3076NA15 (Rod & Bar), BS 3075NA15 (Wire), VdTÜV 412 (All Products).
Plate, Sheet, and Strip: ASTM A 240, ASTM A 480, ASME SA 240, ASME SA 480 (Plate, Sheet, and Strip), ASTM B 409, ASTM B 906, ASME SB 409, ASME SB 906 (Plate, Sheet, and Strip), ASME Code Case 1325 (All Product Forms), ASME Code Case 2339 (Plate), AMS 5871 (Plate, Sheet, and Strip), BS 3072NA15 (Plate & Sheet), BS 3073NA15 (Strip), VdTÜV 412 (All Products), ISO 6208 (plate, sheet and strip).
Pipe and Tubes: ASTM B 163 & ASME SB 163 (Seamless Condenser & Heat Exchanger Tubes), ASTM B 407, ASTM B 829, ASME SB 407, ASME SB 829 (Seamless Pipe & Tubes), ASTM B 514, ASTM B 775, ASME SB 514, ASME SB 775 (Welded Pipe), ASTM B 515, ASTM B 751, ASME SB 515, ASME SB 751(Welded Tubes), ASME Code Case 1325 (All Product Forms), ASME N-20 (Cold Worked Seamless Condenser and Heat Exchanger Tubes for Nuclear Service), BS 3074NA15 (Seamless Pipe & Tubes), VdTÜV 412 (All Products), ISO 6207 (Seamless Tubing).
Other Product Forms: ASTM B 366 & ASME SB 366 (Fittings)
Chemical Composition
|
UNS Designation |
N08800 |
N08810 |
N08811 |
|
Incoloy Alloys |
800 |
800H |
800HT |
|
Nickel |
30.0 - 35.0 |
30.0 - 35.0 |
30.0 - 35.0 |
|
Chromium |
19.0 - 23.0 |
19.0 - 23.0 |
19.0 - 23.0 |
|
Iron |
39.5 min. |
39.5 min |
39.5 min. |
|
Carbon |
0.10 max |
0.05 - 0.10 |
0.06 - 0.10 |
|
Aluminum |
0.15 - 0.60 |
0.15 - 0.60 |
0.25 - 0.60 |
|
Titanium |
0.15 - 0.60 |
0.15 - 0.60 |
0.25 - 0.60 |
|
Aluminum + Titanium |
0.30 - 1.20 |
0.30 - 1.20 |
0.85 - 1.20 |
|
ASTM Grain Size |
Not Specified |
5 or Coarser |
5 or Coaser |
INCOLOY 800 / 800H / 800HT SEAMLESS TUBES
UNS No: UNS N08800
Werkstoff Nr: 1.4876
Common Trade Names: Incoloy 800, Ferrochronin 800, Nickelvac 800, Nicrofer 3220
The above names are trade names and/or trademarks of specific manufactures including Special Metal Corporation. Prosaic Steel & Alloy is not affiliated with any manufacturer(s). Orders will be filled to meet specifications from any available source(s). Names are listed solely for reference to help identify products consistent with listed specifications
Specifications Incoloy 800 / 800H / 800HT Tubes -UNS N08800
Product Range -Seamless tubes 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk.
Specifications- B 163 / B 407.
Finish Conditions-Cold Drawn Solution Annealed & Pickled / Cold Drawn Bright annealed / NACE MRO 175
